Hyundai WIA KF7700B/50 II
Vertical Machining Center
Overview
The KF7700B/50 II is designed by Hyundai WIA with years of experience and the latest technology, maximizes productivity and provides stiffness and rigidity. KF7700B/50 II offers Hyundai value at an economical and affordable price, and provides high productivity and profitability and matches typical of complex, contoured geometry associated with medical production.
Machine Features
- Hyundai Wia FANUC i control
- 20.1 HP spindle motor (24.8 HP optional)
- 8,000 RPM direct-driven spindle (6,000 RPM two-step geared spindle optional)
- Table size: 65 in x 30 in
- Table load capacity: 3,307 lb
- Spindle oil chiller system optional
- Big Plus dual-contact spindle taper (BCV No. 50)
- Rapid traverse rates: X and Y axes 1,181 IPM, Z-axis 945 IPM
- All-axis large box guideways
- Automatic tool changer with 24 tools (30 tools optional)
- Y-shaped ribbed column structure
- Metal plate coupling on all axes
- 290 PSI through-spindle coolant
- Remote manual pulse generator
- Spindle speed override range: 0 to 150 percent in 10 percent increments
- Massive Meehanite cast iron machine base
- Double pre-tensioned ball screws
- Rigid tapping capability
- Program and data protection key switch
- Slanted telescopic way covers
- Chip conveyor with 38.6 in discharge height (side-left discharge)
- Flood coolant system with large separate coolant tank
- Three-color tower signal light
- Full enclosure splash guard
Request a Quote
Click to Request QuoteSpecifications
| Table Size | 65 x 29.9 in. |
| Magazine | 24 |
| Spindle RPM | 8,000 |
| Spindle Taper | BCV 50 |
| Spindle HP | 20 |
| Spindle Torque | 210 |
| Rapids(X) | 1181 |
| Rapids(Y) | 1181 |
| Rapids(Z) | 945 |
| Travel(X) | 59.1 |
| Travel(Y) | 29.9 |
| Travel(Z) | 25 |
