Hyundai WIA KBN135C
Horizontal Machining Center
Overview
The KBN 135C is manufactured using the latest state-of-the-art manufacturing technology and is one of the most versatile members of HYUNDAI-WIA's outstanding line of CNC Horizontal Boring Machines. The KBN135C, Column Moving type, has been designed to meet the demanding requirements found in today metal working market.
Machine Features
- FANUC 31i-B control
- 2,500 RPM spindle with three-speed geared transmission
- 35 HP spindle motor
- Spindle oil chiller system
- CAT 50 spindle taper
- W-axis spindle with 27.6 in (700 mm) stroke
- Rapid traverse rates: X, Y, Z axes 394 IPM; W-axis 315 IPM
- Wide induction-hardened, precision-ground guideways
- Linear and rotary scales standard on all axes
- Air semi-rising slideways on X and Z axes
- Column-moving type structure with Y and Z axes
- T-slot work table
- Automatic tool changer with 60 tools
- 290 PSI through-spindle coolant
- Oil-jacket spindle cooler
- Massive Meehanite cast iron machine base
- Double pre-tensioned ball screws
- Rigid tapping capability
- Portable manual pulse generator
- Program and data protection key switch
- Metered piston distributor lubrication system
- Slanted telescopic way covers
- Chip conveyor with 45 in discharge height
- Flood coolant system with large separate coolant tank
- Three-color tower signal light
Request a Quote
Click to Request QuoteSpecifications
| Table Size | 78.7 x 70.9 in. |
| Magazine | 60 |
| Spindle RPM | 2,500 |
| Spindle Taper | CAT 50 |
| Spindle HP | 35 |
| Spindle Torque | 2712 |
| Rapids(X) | 394 |
| Rapids(Y) | 394 |
| Rapids(Z) | 394 |
| Travel(X) | 157.5 |
| Travel(Y) | 98.4 |
| Travel(Z) | 78.7 |
