Twin Turret Turning Center - Doosan Puma TT2500

 Multi-axis turning center combines Y-axis milling, twin turrets, and dual opposing spindles into one machine.

High performance turning center featuring equal capacity opposing spindles, with upper and lower turrets on a hardened and ground box way bed. Simultaneous machining on both spindles combined with Y-axis machining capability can double your productivity.

Machine Specs:
Recom. Turning diameter in. 10.0
Max. Turning Dia. in. Upper: 15.4 / Lower: 11.8
Max. Turning Length in. 30.7
Bar working diameter in. 3.0
Spindle Motor (Int./Cont.) Hp 35/30
Spindle Speed rpm 3,500
Rotary Tool Spindle Motor (10 min/Cont) Hp 7.5/2.0
No. of Tool Station st 12+12
X1/2-axis Rapid Traverse ipm 787
Z1/2-axis Rapid Traverse ipm 945
B-axis Rapid Traverse ipm 945
Y-axis Rapid Traverse ipm 295
